Line Insulators

AC & DC LINE INSULATORS - (Suspension & Tension) Composite Long Road Insulators for Transmission Line

Voltage Level	Specified Machanical / Bending Load	Minimum Creepage / Leakage Distance	Section Length / Structure Height
1200KV	210 KN/240 KN/320 KN/ 400KN	31mm/kv or 25m/kv	10 to 12 Meters
765KV	120 KN/160 KN/180 KN/ 210 KN	31mm/kv or 25m/kv	7.5 to 8 Meters
500KV	120 KN/160 KN/180 KN/ 210 KN	31mm/kv or 25m/kv	5.5 to 5.5 Meters
400KV	120 KN/160 KN/180 KN/ 210 KN	31mm/kv or 25m/kv	3.25 to 4.25 Meters
330KV	90 KN/120 KN/160 KN/ 180 KN	31mm/kv or 25m/kv	1.8 to 2.5 Meters
220KV	70 KN/90 KN/120 KN/ 160 KN	31mm/kv or 25m/kv	1.4 to 1.8 Meters
154KV	90 KN/120 KN/160 KN/ 180 KN	31mm/kv or 25m/kv	1.4 to 1.8 Meters
132KV	70 KN/90 KN/120 KN/ 160 KN	31mm/kv or 25m/kv	1.1 to 1.4 Meters
110KV	90 KN/120 KN/160 KN/ 180 KN	31mm/kv or 25m/kv	0.8 to 1.4 Meters
66KV	70 KN/90 KN/120 KN/ 160 KN	31mm/kv or 25m/kv	0.5 to 0.8 Meters

×

Post Insulators

Composite Polymer POST Insulators for Substation Equipment

Voltage Level	Specified Machanical / Bending Load	Minimum Creepage / Leakage Distance	Section Length / Structure Height
400KV	90 KN/ 120KN/ 160KN/ 180KN	31mm/kv or 25mm/kv	As per Customer Requirement
330KV	90 KN/ 120KN/ 160KN/ 180KN	31mm/kv or 25mm/kv	As per Customer Requirement
220KV	70 KN/ 90KN/ 120KN/ 160KN	31mm/kv or 25mm/kv	As per Customer Requirement
154KV	70 KN/ 90KN/ 120KN/ 160KN	31mm/kv or 25mm/kv	As per Customer Requirement
132KV	70 KN/ 90KN/ 120KN/ 160KN	31mm/kv or 25mm/kv	As per Customer Requirement
110KV	70 KN/ 90KN/ 120KN/ 160KN	31mm/kv or 25mm/kv	As per Customer Requirement
66KV	70 KN/ 90KN/ 120KN/ 160KN	31mm/kv or 25mm/kv	As per Customer Requirement
36KV	70 KN/ 90KN/ 120KN/ 160KN	31mm/kv or 25mm/kv	As per Customer Requirement

×

Pin Insulators

Composite Polymer PIN Insulators for DIstribution Lines

Voltage Level	Specified Machanical / Bending Load	Minimum Creepage / Leakage Distance	Section Length / Structure Height
36 KV	5 KN/ 10 KN/ 20 KN	31mm/kv or 25 mm/kv	As per Customer Requirement
33 KV	5 KN/ 10 KN/ 20 KN	31mm/kv or 25 mm/kv	As per Customer Requirement
24 KV	5 KN/ 10 KN/ 20 KN	31mm/kv or 25 mm/kv	As per Customer Requirement
12 KV	4 KN/ 5 KN/ 10 KN	31mm/kv or 25 mm/kv	As per Customer Requirement
11 KV	5 KN/ 5 KN/ 10 KN	31mm/kv or 25 mm/kv	As per Customer Requirement

×

IEC Standard

Suspension Insulators Suspension Insulator Fog Type Suspension Insulator Special Type New Products

×

ANSI Standard

Suspension Insulator DC Type Suspension Insulator Fog Type Suspension Insulator Standard Type B&S Suspension Insulator Standard Type C&T

×
